Technische Daten
Brand | AV Stumpfl |
---|---|
Model | PIXERA one |
Processor | Intel Xeon SP |
RAM | 24 GB ECC RAM |
Memory | 480 GB SSD |
Compatible signal | 1 – 4 DP 1.4 possible, 1 x IPMI LAN, 2 x 10 Gb LAN, 2 x USB2 (back side), 2 x USB3 (back side), 2 x USB3 (front), 3,5mm Jack, 3G-SDI possible, ADAT possible, AES/EBU possible, GUI outputs possible, HDMI 2.0 possible, MIDI possible, SPDIF possible |
Software | 3D Visualization, AV Stumpfl Server OS, Avio Manager 2D, Backup and Snapshot Manager (snapshot and freezing option), Local Editing, Network Master / Manager, Rendering (Output, Visu), Vioso camera calibration possible, Wings RX, Wings Touch |
Dimensions | 1 height unit, 19" width |
Features | 8K real-time renderengine, EDID Management, Frame and genlock possible, Integrated projector and LED databases, Intuitive 2D and 3D projection mapping workflow, NDI-Streaming, previsualization, redundant power supply, VIOSO camera calibration, 24/7-continuous operation, rackable |
